Product Model:
Brief Introduction: Product description LNG full containment tanks have been developing alongside the LNG industry, with LNG storage becoming increasingly large-scale and at normal pressure. Domestic design and manufacturing have reached 50,000m3, and single units of 250,000m3 and 160,000m3 LNG normal pressure storage tanks have been established along the coast to receive ship-borne LNG. Currently, the LNG storage tanks designed, manufactured, and installed domestically are mainly 5,000m3 and

Product Description
LNG Full Containment Tank
With the development of the LNG industry, LNG storage is becoming increasingly large-scale and at normal pressure. Domestic design and manufacturing have reached 50,000m³, and single units of 250,000m³ and 160,000m³ LNG normal pressure storage tanks have been established along the coast to receive ship-borne LNG. Currently, the LNG storage tanks designed, manufactured, and installed domestically are mainly 5,000m³ and 10,000m³, widely used in LNG liquefaction plants or LNG peak shaving stations. The amount of LNG produced from industrial waste gas is generally small, and 1,000m³ LNG storage tanks are commonly used.

Product Details
Main Structure Type
Vertical, cylindrical, double metal, internal roof, external arch roof, high thermal angle protection
The interlayer uses pearlescent sand, elastic felt, and foam glass bricks for insulation.

Process System
01. Purging System
02. Liquid Inlet System
03. Liquid Discharge System (External and Submersible)
04. Pump Backflow System
05. Interlayer Nitrogen Supply System
06. Liquid Level and Pressure Measurement System
07. Temperature Measurement System
08. Gas Emission System
09. BOG Pipeline System
10. Analysis and Sampling System
11. Safety System
12. Pressure Stabilization System
13. Fire Protection System

Product Description
4×10000m³ LNG Normal Pressure Storage Tanks
With the development of the LNG industry, LNG storage is becoming increasingly large-scale and at normal pressure. Domestic design and manufacturing have reached 50,000m³, and single units of 250,000m³ and 160,000m³ LNG normal pressure storage tanks have been established along the coast to receive ship-borne LNG.
Currently, the LNG storage tanks designed, manufactured, and installed domestically are mainly 5,000m³ and 10,000m³, widely used in LNG liquefaction plants or LNG peak shaving stations. The amount of LNG produced from industrial waste gas is generally small, and 1,000m³ LNG storage tanks are commonly used.

Product Details
Main Structure Type
Vertical cylindrical, double-walled, flat bottom, arch top (200~50000m³), above 6000m³ is floating roof type (self-supporting roof).
Insulation Method: Double-walled powder accumulation insulation
Basic Form: High platform type

Process System
01. Purging System
02. Liquid Inlet System
03. Liquid Discharge System (External and Submersible)
04. Pump Backflow System
05. Interlayer Nitrogen Supply System
06. Liquid Level and Pressure Measurement System
07. Temperature Measurement System
08. Gas Emission System
09. BOG Pipeline System
10. Analysis and Sampling System
11. Safety System
12. Pressure Stabilization System
13. Fire Protection System

Foam Glass Brick Introduction
● Lightweight, around 150KG/m³;
● Low thermal conductivity, below 0.050W/m*k (38℃), stable thermal performance;
● Waterproof
● Low water absorption, around 0.2%
● Non-combustible;
● No mold, no corrosion;
● High strength, compressive strength ≥0.8MPa, can resist acidic corrosion (except hydrofluoric acid);
● Non-toxic, contains no CFC (chlorofluorocarbon) and HCFC (hydrochlorofluorocarbon);
● Stable physical and chemical properties, dimensionally stable.
LNG Storage Tank Design, Manufacturing, and Acceptance Standards
● European Standard BSEN14620 "Design and On-site Manufacturing of Vertical, Cylindrical, Flat-bottomed Storage Tanks for Cooling Liquefied Storage with Operating Temperatures between 0℃ and -165℃"
● JB/T9077-1999 "Powder Ordinary Insulation Storage Tanks"
● JB/T4735-1997 "Steel Welded Normal Pressure Vessels"
● American Standard API620 "Design and Construction of Large Welded Low-pressure Storage Tanks"
● JB/T4730-2005 "Non-destructive Testing of Pump Pressure Equipment"
● GB50128-2005 "Construction and Acceptance Specifications for Vertical Cylindrical Steel Welded Storage Tanks"
● GB/T20368-2006 "Liquefied Natural Gas (LNG) Production, Storage, and Transportation"

LNG Flat-bottom Storage Tank LNG Full Containment Tank LNG Large Normal Pressure Low-temperature Liquid Storage Tank
